Bettermaker Mastering Equalizer
Produktinformationen "Bettermaker Mastering Equalizer"
Features:
- 100% analog audio signal path
- USB connectivity with MAC/PC
- all parameters are digitally controlled via touchscreen and/or DAW (with dedicated plugin)
- 399 presets, total recall, A/B comparison
- 5-inch capacitive touchscreen with back-light and multi-touch functionality, four encoders with push-button action for ease of control
- stereo, dual-mono and mid/side operation modes with solo function
- stereo 12 or 24dB/oct high-pass filter with adjustable cutoff frequency (15Hz – 150 hz) and resonance
- four stereo parametric filters with 15dB boost/cut range, variable Q (0.2 – 3):
- EQ1: 23Hz – 400Hz (bell/shelf)
- EQ2: 80Hz – 2kHz (bell)
- EQ3: 400Hz – 10kHz (bell)
- EQ4: 1kHz – 23kHz (bell/shelf)
- stereo passive equalizer with extended hi-boost section (23 and 28 kHz) and separate frequencies for low-boost and low-cut sections
- stereo 12dB/oct low-pass filter with adjustable cutoff frequency
- adjustable output level (+/- 12dB)
- Gain Lock and Auto-Q functions
- on-board measurement of PEAK/RMS levels and RTA analyzer
- on-screen live representation of the EQ curve
balanced stereo input (XLR), 23dBu max input level (THD < 0.1%)
balanced stereo output (XLR), 23dBu max output level (THD < 0.1%)
Operating Level: +4dBu
Input impedance (differential): 48kΩ (for balanced signal)
Output Impedance: 50Ω + 50Ω (electronically balanced)
Frequency response 5Hz to 30kHz; +/- 0.1dB
Dynamic range: 115 dB @ +18 dBu, 20 kHz BW
THD+N: CMRR: max 80 dB @ 3 kHz, min 55 dB @ 50Hz, 20 kHz BW
Crosstalk: min -90 dB @ 1KHz, max -55 dB @ 30Hz, +18 dBu, 20 kHz BW
2U enclosure, 230mm deep
115/230V switch
advanced linear power supply with toroidal AC mains transformer
Maximum power consumption: 30W
Shipping weight: 5.5 kg
